| Sensor | FX, CMOS sensor 35.9 x 24.0 mm, 24.7 MP |
| Effective resolution | 24.3 megapixels |
| Color | 12- or 14-bit |
| Image format | NEF (RAW): 12 or 14 bits, lossless or compressed. JPEG: JPEG-Baseline compatible with good (approx. 1: 4), normal (approx. 1: 8), or base (approx. 1:16) compression (size priority); Optimal quality compression is available. NEF (RAW) + JPEG: single image saved in NEF (RAW) and JPEG formats |
| Resolution when recording images | FX (36x24) viewfinder image area 6016 x 4016 (L), 4512 x 3008 (M), 3008 x 2008 (S). Image area in viewfinder DX (24x16) 3936 x 2624 (L), 2944 x 1968 (M), 1968 x 1312 (S). FX-format still images taken with live view 6016 x 3376 (L), 4512 x 2528 (M), 3008 x 1688 (S). DX Images When Shooting a Movie in Live View 3936 x 2224 (L), 2944 x 1664 (M), 1968 x 1112 (S) |
| Video recording | MOV, H.264 / MPEG-4, Linear PCM, 1920 x 1080; 30 p (sequential unfolding), 25 p, 24 p. 1280 x 720; 60 p, 50 p, 30 p, 25 p. The actual frame rates for 60 p, 50 p, 30 p, 25 p, and 24 p, respectively, are 59.94, 50, 29.97, 25, and 23.976 frames / sec; the options support both high and normal image quality |
| Bayonet | Nikon F-mount |
| Increased focal length compared to 35mm standard | 1x |
| Image stabilization | Yes (with Nikon VR lenses) |
| Type | Nikon Multi-CAM 4800 auto-focus sensor module with TTL phase detection, fine-tuning, 39 focus points (including 9 cross-type sensors; central 33 focus points available at apertures slower than f / 5 , 6 and faster than f / 8, and the center 7 focal points are available at f / 8) and AF assist beam (range approx. 0.5 - 3 m / 1 foot and 8 inches - 9 feet and 10 inches) |
| Work modes | Single point AF, 9-, 21- or 39-point AF with dynamic zone, 3D tracking, AF with AF |
| Light sensitivity | ISO 100-6400 in 1/3 or 1/2 EV increments. It can also be set to approx. 0.3, 0.5, 0.7 or 1 EV (ISO 50 equivalent) below ISO 100 or approx. 0.3, 0.5, 0.7, 1 or 2 EV (ISO 25 600 equivalent) over ISO 6400; automatic ISO sensitivity control is available |
| Shutter type | Focusing shutter with vertical stroke and electronic control |
| Shutter speed | 1/4000 - 30 sec increments of 1/3 or 1/2 EV, bulb (continuous manual exposure while the shutter button is pressed), continuous manual exposure for a specified period of time (optional optional ML- L3), X200 |
| Mirror lock | Yes |
| Light meter | Matrix: 3D color matrix measurement II (lenses type G, E and D); color matrix measurement II (other lenses with processors); color matrix metering is available for non-processor lenses if the user provides lens data. Center weighted: 75% sensitivity for a 12mm diameter circle in the center of the frame. The circle diameter can be changed to 8, 15 or 20 mm, or the weight can be based on the average of the whole frame (lenses without a processor use a 12 mm circle or the average of the whole frame). Spot: Measures a circle 4 mm in diameter (about 1.5% of the frame) centered on a selected focus point (at the center focus point when using a lens without a processor). |
| Exposure modes | Automatic (automatic; automatic (flash off)), stage (portrait; landscape; children; sports; close-up; night portrait; night landscape; party / indoors; beach / snow; sunset; dusk / dawn; home portrait pet; candle light; color; autumn colors; food; silhouette; high key; low key); mode with automatic flexible program (P); shutter priority automatic mode (S); aperture priority automatic mode (A); manual mode (M); U1 (user settings 1); U2 (Custom Settings 2) |
| White balance | Automatic (2 types), incandescent, fluorescent (7 types), direct sunlight, flash, cloudy, shaded, with manual user tuning (up to 6 values can be maintained, white spot balance, available live view, color temperature selection (2500 - 10,000 K), all fine-tuned |
| Built-in flash | Yes |
| Effective flash range | Approx. 12/39, 12/39 with manual flash (m / ft, ISO 100, 20˚C / 68˚F) |
| Contact for external flash | Standard ISO 518 hot plug with sync, data contacts and security lock |
| Controls the external flash | TTL: i-TTL flash control via 2016-pixel RGB sensor comes with built-in flash and SB-910, SB-900, SB-800, SB-700, SB-600, SB-400 or SB-300 ; i-TTL balanced flare flash for digital SLR cameras used for matrix and center-weighted measurement, standard i-TTL flash for digital SLR cameras - for spot measurement |
| Maximum external flash sync speed (X-sync) | X = 1/200 sec; Shuts shutter at 1/250 sec or lower (flash range decreases at speeds between 1/200 and 1/250 sec) |
| Display | 8 centimeters / 3.2 inches, approx. 921,000 dots (VGA) TFT LCD display with low temperature polycrystalline silicon with a viewing angle of approx. 170 °; approx. 100% frame coverage and automatic display brightness control with ambient brightness sensor |
| Serial pictures | 1-5 fps (low-speed burst), 6 frames (high-speed burst) or 3 fps (quiet shutter release) |
| Self-timer | 2 sec, 5 sec, 10 sec, 20 sec; 1-9 exposures at intervals of 0.5, 1, 2 or 3 sec |
| Shoot at a set interval | Yes |
| Interfaces | High speed USB, NTSC video output, PAL, HDMI connector Type C with mini-outlets, Stereo mini jack (3.5 mm diameter); Remote Control Cable: MC-DC2 (available separately). GPS unit: GP-1 / GP-1A (available separately), Audio Out: Stereo Mini Jack (3.5mm diameter) |
| Internal memory | None |
| Compatible storage media | SD (Secure Digital Standard) memory cards and UHS-I compatible SDHC and SDXC memory cards |
| Battery | EN-EL15 |
| Electrical adapter | Power adapter EH-5b; requires power connector EP-5B (available separately) |
| Remote control | WR-R10 (WR-A10 Adapter) or WR-1, ML-L3 |
| Dimensions | Approx. 141 x 113 x 82 mm |
| WEIGHT | Approx. 850 g (1 lb. and 14.0 oz.) With battery and memory card, but without camera body cap; approx. 760 g (1 lb and 10.8 ounces; camera body only) |
