Sensor | FX, CMOS sensor 35.9 x 24.0 mm, 24.93 MP |
Effective resolution | 24.3 megapixels |
Color | 12- or 14-bit |
Image format | NEF (RAW): 12 or 14 bits, lossless or compressed. JPEG: JPEG-Baseline format compatible with good (approx. 1: 4), normal (approx. 1: 8), or basic (approx. 1: 16) compression (size priority); optimum quality compression is available. NEF (RAW) + JPEG: Single image saved in NEF (RAW) and JPEG formats |
Resolution when recording images | FX (36x24) viewfinder area: (L) 6016 x 4016, (M) 4512 x 3008, (S) 3008 x 2008. 1,2x (30x20) viewfinder area: (L) 5008 x 3336, (M) 3752 x 2504, (S) 2504 x 1664. DX (24x16) viewfinder image area: (L) 3936 x 2624, (M) 2944 x 1968, (S) 1968 x 1312. Photos with format FX taken with live-view movie: (L) 6016 x 3376, (M) 4512 x 2528, (S) 3008 x 1688. DX-format stills taken when shooting a movie in live view mode: (L) 3936 x 2224, (M) 2944 x 1664, (S) 1968 x 1112. Note: Pictures taken when shooting a live view movie, have a 16: 9 aspect ratio steam offers a choice of DX- and FX-based formats. |
Video recording | MOV, H.264 / MPEG-4, Linear PCM, 1920 x 1080; 60 p (sequential unfolding), 50 p, 30 p, 25 p, 24 p. 1280 x 720; 60 p, 50 p. The actual frame rates for 60 p, 50 p, 30 p, 25 p, and 24 p, respectively, are 59.94, 50, 29.97, 25, and 23.976 frames / sec; the options support both high and normal image quality |
Bayonet | Nikon F-mount |
Increased focal length compared to 35mm standard | 1x |
Image stabilization | Yes (with Nikon VR lenses) |
Type | Advanced Nikon Multi-CAM 3500 II auto-focus sensor module with TTL phase detection, fine-tuning, 51 focus points (including 15 cross-type sensors; f / 8 supported by 11 sensors) and AF assist beam (approx. 0.5-3 m / 1 foot and 8 inches - 9 feet and 10 inches) |
Work modes | Single point AF, 9, 21 or 51 point dynamic area AF, 3D tracking, Grouped area AF, Auto zone AF |
Light sensitivity | ISO 100-12800 in 1/3 or 1/2 EV increments. It can also be set to approx. 0.3, 0.5, 0.7 or 1 EV (ISO 50 equivalent) below ISO 100 or approx. 0.3, 0.5, 0.7, 1 or 2 EV (ISO 51 200 equivalent) above ISO 12 800, has automatic ISO sensitivity control |
Shutter type | Focusing shutter with vertical stroke and electronic control |
Shutter speed | 1/4000 - 30 sec increments of 1/3 or 1/2 EV, bulb (continuous manual exposure while the shutter release is depressed), continuous manual exposure for a specified period of time, X200 |
Mirror lock | Yes |
Light meter | Matrix: 3D Color Matrix Measurement III (lenses type G, E and D); Color Matrix Measurement III (other CPU lenses); non-CPU color matrix metering is available if the user provides lens data. Center Weighted: Gives approx. 75% of circle information with a diameter of 12 mm in the center of the frame. The circle diameter can be changed to 8, 15 or 20 mm, or the weight can be based on the average of the whole frame (non-CPU lenses use a 12 mm circle). Spot: Measures a 4mm circle (about 1.5% of the frame) centered on the selected focus point (at the center focus point when using a non-CPU lens). Weighing light sections: Available with G, E and D lenses; is equivalent to center-weighted when other lenses are used. |
Exposure modes | Automatic modes (automatic; automatic (flash off)); stage modes (portrait; landscape; children; sports; close-up; night portrait; night landscape; party / indoors; beach / snow; sunset; dusk / dawn; pet portrait; candle light; color; autumn colors; food ); special effects modes (night vision; color sketch; thumbnail effect; selective color; silhouette; high key; low key); mode with automatic flexible program (P); shutter priority automatic (S); automatic aperture priority (A); manual mode (M); U1 (user settings 1); U2 (Custom Settings 2) |
White balance | Automatic (2 types), incandescent, fluorescent (7 types), direct sunlight, flash, cloudy, shaded, custom (up to 6 values can be maintained, white spot measurement, available with live view), color temperature selection (2500 K to 10,000 K), all with fine-tuning. |
Built-in flash | Yes |
Effective flash range | Approx. 12/39, 12/39 with manual flash (m / ft, ISO 100, 20˚C / 68˚F) |
Contact for external flash | Standard ISO 518 hot plug with sync, data contacts and security lock |
Controls the external flash | TTL: i-TTL flash control via an RGB sensor of approximately 91,000 pixels comes with a built-in flash; i-TTL balanced fill flash for digital SLR is used for matrix and center weighted and light weighted measurement, the standard i-TTL flash is for digital SLR with spot measurement |
Maximum external flash sync speed (X-sync) | X = 1/200 sec; Shuts shutter at 1/250 sec or slower (flash range decreases at speeds between 1/200 and 1/250 sec) |
Display | 8 inches (3.2 inches) diagonal. TFT LCD tilting display made of low temperature polycrystalline silicon with approx. 170 °, approx. 100% frame coverage and brightness and angle adjustment Approx. 1,229,000 dots (VGA; 640 x RGBW x 480 = 1,228,800 dots) |
Serial pictures | Approx. 6fps, 1-6fps (CL), 6.5fps (CH), or 3fps (Qc) |
Self-timer | 2 sec, 5 sec, 10 sec, 20 sec; 1-9 exposures at intervals of 0.5, 1, 2 or 3 sec |
Shoot at a set interval | Yes |
Interfaces | High speed USB, NTSC video output, PAL, HDMI connector Type C with mini-outlets, Stereo mini jack (3.5 mm diameter); Wi-Fi (wireless LAN) communication protocols IEEE 802.11b, IEEE 802.11g, Audio output: Stereo mini jack (3.5 mm diameter), Wireless remote controls: WR-1, WR-R10 (available separately). Remote Control Cable: MC-DC2 (available separately). GPS unit: GP-1 / GP-1A (available separately) |
Internal memory | None |
Compatible storage media | SD, SDHC (UHS-I compliant), SDXC (UHS-I compliant), Slot 2 can be used for overflow, for backups, or for separate backup of NEF + JPEG backups; photos can be copied from one card to another. |
Battery | EN-EL15 |
Electrical adapter | Power adapter EH-5b; requires power connector EP-5B (available separately) |
Remote control | WR-R10 (WR-A10 Adapter) or WR-1, ML-L3 |
Dimensions | Approx. 140.5 x 113 x 78 mm |
WEIGHT | Approx. 840 g (1 lb. and 13.7 ounces) with battery and memory card, but without camera body cap; approx. 750 g (1 lb and 10.5 ounces; camera body only) |
