Description
Characteristics
| General features | |
| Sensor | Chamomile format (36 x 24mm) 22 megapixel RGB CMOS sensor |
| Effective resolution | 21.1 megapixels |
| ADC | 14-Bit |
| Color space | Adobe RGB, sRGB |
| Image format | RAW (.CR2 14-bit); sRAW1; sRAW2; RAW + JPEG; sRAW1 + JPEG; sRAW2 + JPEG; JPEG |
| Resolution when recording images | JPEG: 5616x3744 (L), 4080x2720 (M), 2784x1856 (S); RAW: 5616x3744; sRAW1: 3861x2574; sRAW2: 2784x1856 |
| Video recording | HD 1920 x 1080 (16: 9) up to 12 minutes (Quicktime 1080p H.264; 38.6 Mbits / sec); SD 640 x 480 (4: 3) up to 24 minutes (Quicktime 480p H.264; 17.3 Mbits / sec); 30 fps; Maximum file size: 4GB |
| Record sound | Linear PCM |
| Compatible with lenses | Lenses with Canon EF mount |
| Ratio indicating equivalent focal length to Laika frame format (36 x 24mm) | 1x |
| Bayonet | Canon EF mount |
| Image stabilization | Yes (with Canon IS lenses) |
| Type | 9 points (center is cross type + 6 invisible assist points) TTL phase detection autofocus (CMOS sensor); Sensitivity range: -0.5EV to + 18EV (at ISO100 and 23 ° C); ability to adjust focus for a specific lens; Live View (Live mode) mode uses autofocus with contrast detection using the shooting sensor |
| Work modes | One-shot autofocus (One shot), Continuous autofocus (AI Servo), One-shot auto-shift and AI Servo (AI Focus), Manual focus (M); Zones: Auto, Manual selectable; in Live View (Live mode) the autofocus zone can be selected anywhere in the frame |
| Pre-lifting the mirror | Yes |
| Light sensitivity | ISO - AUTO (100-3200), L1 (50) 100, 200, 400, 800, 1600, 3200, 6400, H1 (12800), H2 (25600) - 1/3 or 1EV step |
| Shutter type | Electronically controlled focal shutter |
| Shutter speed | 30 - 1/8000 sec (1/3 or 1/2 EV step) + B |
| Light meter | 35-zone TTL (through lens) measuring system operating at maximum aperture; Sensitivity range: 1EV to 20EV (ISO 100, 50mm f / 1.4, 23 ° C); Measuring modes: Evaluative (35-zone associated with all focal points); Partial (center of frame 8% of viewfinder); Spot (center of frame 3.5% of viewfinder); Center-weighted (measures full frame but center-priority) |
| Exposure modes | Automatic with the ability to change the exposure parameter pair (P), Automatic with shutter priority (Tv), Automatic with aperture priority (Av), Automatic with depth of field priority (A-DEP); Manual (M); Creative Auto; Exposure compensation from-2.0 EV to +2.0 EV (1/3 or 1/2 EV steps); Exposure wedge |
| White balance | Automatic (TTL White Balance with Shooting Sensor), 6 Ready Modes, Kelvin Color Temperature Setting (2500 - 10000 K in 100K increments); White measurement using white or gray standard, Precision adjustment, Wedge |
| Top number (m) | ... |
| Ready shot templates | 3 customizable modes |
| Flash control | E-TTL II Flash Control EX - Speedlite Flash compensation: -2 EV to +2 EV (1/3 or 1/2 EV steps) |
| Built-in flash | None |
| Synchronous shutter speed | 1/200 sec. |
| Contact for external flash | Yes - standard Hot Shoe |
| Interface | USB 2.0 Hi-Speed (Mini-B); AV output (PAL / NTSC); HDMI output; Microphone Input; N3 type connector for cable remote control; PC Sync flash terminal; Communication terminal on base for WFT-E4; InfraRed |
| Display | 3.0 "Clear View TFT LCD 920 000 pixels |
| Serial pictures | 3.9 fps for Large / Fine JPEG (up to 78 frames (up to 310 frames with UDMA memory)); for RAW (up to 13 frames) |
| Self-timer | 2, 10 seconds |
| Internal memory | None |
| Compatible storage media | Compact Flash Type I or II (inc. FAT32) |
| Battery | LP-E6 Rechargeable Lithium Ion Battery Pack (7.4V, 1800mAh) |
| Info display | Yes |
| Remote control | Wireless Controller LC-5, Remote Controller RC-1, Remote Controller RC-5 |
| Dimensions | 152 x 113.5 x 75 mm |
| WEIGHT | 810 g (without battery) |
| DISPLAY | |
| Viewfinder | Pentaprism; Built-in diopter correction (-3.0 to +1.0); Frame coverage: 98%; Magnification: approx. 0.71x with 50mm lens focused on infinity; Focal Screen: Standard Focusing Screen Precision Matte Eg-A (three types of removable focus screens optional) |
| Languages | 25 languages |
| General | |
| Warranty card |
Box contents
Батерия Cаnon LP-E6 Rechargeable Lithium-Ion Battery Pack (7.4V, 1800mAh)
Зарядно устройство LC-E6 Battery Charger
STV-250N Mini A/V Angled Male to 3 RCA Male A/V Cable
Чашка за визьор Canon Eyecup Eb
Капачка за тяло Canon RF-3 Camera Cover
Ремък
IFC-200U USB Cable
EOS Digital Solutions CD-ROM
Ръководство за употреба
