Sensor | APS-C format (22.2 x 14.7 mm) 16.9 megapixel RGB CMOS sensor |
Effective resolution | 12.2 megapixels |
ADC | 14-Bit |
Color space | Adobe RGB, sRGB |
Image format | JPEG: Fine, Normal (Exif 2.30 compatibility) / Design rule for Camera File (2.0), RAW: RAW (14bit, Canon original RAW 2nd edition), Digital Print Order Format [DPOF] Version 1.1 compatibility |
Resolution when recording images | 4 928 x 3 264 (L) 3 696 x 2 448 (M) 2 464 x 1 632 (S) |
Video recording | 1280 x 720 (29.97, 25 fps) |
Record sound | Yes - Mono |
Compatible with lenses | Lenses with Canon EF / EF-S mount |
Ratio indicating equivalent focal length to Laika frame format (36 x 24mm) | 1.6x |
Bayonet | Canon EF / EF-S |
Image stabilization | Yes (with Canon IS lenses) |
Type | 9 AF points (at f / 5.6 - center cross AF point), EV 0 - 18 (at 23 ° C and ISO100), Intelligent single frame AF Next object AF |
Work modes | One-shot autofocus (One shot), Continuous autofocus (AI Servo), One-shot auto-shift and AI Servo (AI Focus), Manual focus (M); Zones: Auto, Manual selectable; in Live View (Live mode), the autofocus zone can be selected anywhere in the frame, Face Detection Live mode |
Pre-lifting the mirror | Yes |
Light sensitivity | Auto (100-6400), 100-6400 (in 1 step) |
Shutter type | Electronically controlled focal plane shutter with electronic first barrier |
Shutter speed | 30-1 / 4000 s (in 1/2 or 1/3 steps), Unlimited exposure (Full shutter speed range. Available range varies depending on shooting mode.) |
Light meter | TTL maximum aperture measurement with 63-zone SPC system (1) Estimated metering (at each AF point) (2) Partial center metering (approx. 10% of viewfinder) (3) Center centered priority metering |
Exposure modes | Automatic with the ability to change the exposure parameter pair (P), Automatic with shutter priority (Tv), Automatic with aperture priority (Av), Automatic with depth of field priority (A-DEP); Manual (M); Auto; Exposure compensation from - 5.0 EV to +5.0 EV (1/3 or 1/2 EV steps); Exposure wedge |
White balance | Automatic, Daylight, Shadow, Cloudiness, Tungsten, White Fluorescent Light, Flash, Custom. White Balance Correction: 1. Blue / Amber +/- 92. Magenta / Green +/- 9 |
Top number (m) | 9,2 Leading number (ISO 100, meters) |
Ready shot templates | 6 |
Flash control | E-TTL II with EX Series Speedlite, multi-flash wireless control |
Built-in flash | Up to 17 mm focal length (35 mm equivalent: 27 mm) |
Synchronous shutter speed | 1/200 sec. |
Contact for external flash | Yes - standard Hot Shoe |
Interface | USB 2.0 Hi-Speed (Mini-B); Video output (PAL / NTSC); HDMI Type C; E3 type connector for cable remote control, 3.5mm microphone input |
Display | 6.8 cm (2.7 ”) TFT, approx. 230 K pixels |
Serial pictures | Max. JPEG approx. 3fps for approx. 830 images¹³Max. RAW approx. 2fps for approx. 5 images |
Self-timer | Single shots, Photo series, Self-timer (2s, 10s, 10s + photo series 2-10) |
Status display | Yes |
Internal memory | None |
Compatible storage media | SD card, SDHC card or SDXC card |
Battery | LP-E10 |
Remote control | Remote Controller RC-6 (optional); |
Dimensions | 129.9 x 99.7 x 77.9 mm |
WEIGHT | 495g (without battery) |
